GEN 2 – 2218

Montag’s GEN 2 metering system has a unique modular design that allows it to be adapted to your needs as your operation changes and evolves for years to come.

The 2218 GEN 2 model is capable of blending 2 products at different rates from two poly bins (9 tons of total capacity).  It also can be configured with up to 18 rows and up to 4 sections. 

The reversible plenum and configurable platform allow for very flexible mounting options.

It is also configured with a sealed plastic lid which was updated for model year 2025.

Model	Rows	Hydraulic Capacity	Hydraulic Pressure	Pressure	Return	Case Drain
GEN 2 – 2218	Up to 18	20 gpm (76 lpm)	2850 psi (197 bar)	3/4 inch	1 inch	1/2 inch

Option	Benefit
Fully Configurable	The GEN 2 series is designed to adapt to your needs and can be easily reconfigured in the field. Customizable Options (GEN 2 2218): Capacity: 9 tons Product Blends: 2 Meter Outputs: Up to 18 (before splitters) Section Control: 1–4 sections Bin Color: Gray, Yellow, or White Platform Orientation Slidegate: Hydraulic Technology & Scale Options
Bin Options	The 2218 includes two sealed bins (9 tons total capacity). They can be scaled and metered independently (2 products) or “chained” together for 1 product application in the MDRC controller. Available in gray, yellow, or white poly. For Model 2025, Montag updated the lid design to use a sealed plastic lid. This update improves the lid seal while providing a more ergonomic solution. A full set of (4) 3/4” and (2) 1/2” screens are included.
Efficient Hydraulic Design	The 2218 uses a Crary fan with an efficient hydraulic design that allows machine to operate on a single hydraulic SCV. Built for reliable use in fertilizer and cover crop applications. Pressure relief protects key hydraulic components like the fan motor seal.
Air Delivery	Up to eighteen 2” outlets, easily reconfigured. Splitters can be added to serve more rows at lower rates.
Section Control	Supports up to 4 sections. Sections can be added later. Sections are controlled by hydraulic motors and PWM valves for durability.
Dry Controller	47 Pin (JDRC2000, Raven RCM) Options for integrated load cell wiring Montag Dry Rate Controller (MDRC) (ISO) Option to include an ISO tee
Scales	Point ISO Scales Scale-Link ISO Scales Load Cells Only (Scale Ready) Note: Controller compatibility varies with selected options. See the Technology Brochure for details.
Slide-Gates	Hydraulic slide-gates allow farmers to segregate the product from the metering augers for easier clean-out and maintenance.
Deck & Ladder	Ladder can be mounted on the front or rear and left or right side of machine.
Additional Features	Cart Option: Mountable to Montag’s 12 ton cart or directly onto some toolbars. Blockage Sensors: Wireless J.Assy kits available. Light Kit: LED transport lights are available. Warranty: 3-year coverage for peace of mind
